Топливная система экскаватора гусеничного модели III Doosan SOLAR 170-III
Топливная система экскаватора гусеничного модели III Doosan SOLAR 170-III со списком деталей и комплектацией. Каждую деталь можно приобрести в наличии и под заказ с дотавкой по всей России
Код подсистемы:240
Наименование:FUEL SYSTEM
Версия:2021-7118EF
FUEL SYSTEM SOLAR 170-III
| Поз. | Код | Наименование | Кол | Прим. | |
|---|---|---|---|---|---|
| 1 | 65.10101-7265 | NOZZLE HOLDER ASS'Y | 6 |
65.10101-7295
|
|
| 1 | 65.10101-7295 | NOZZLE HOLDER ASS'Y | 6 | ||
| 11 | 65.12301-5816 | PIPE;FUEL | 1 | ||
| 12 | 06.78144-2204 | SCREW;HOLLOW | 1 | ||
| 13 | 06.56190-0706 | RING;SEAL A14X20 | 2 | ||
| 14 | 65.12301-5817 | PIPE;FUEL | 1 | ||
| 15 | 06.78144-2204 | SCREW;HOLLOW | 1 | ||
| 16 | 06.56190-0706 | RING;SEAL A14X20 | 2 | ||
| 17 | 65.97401-6009 | PIPE CLIP ASS'Y | 1 | ||
| 18 | 65.12301-5210 | PIPE;FUEL(RETURN) | 1 | ||
| 19 | 65.98150-0015 | SCREW;HOLLOW | 7 |
65.98150-0015B
|
|
| 19 | 65.98150-0015B | SCREW;HOLLOW | 7 | ||
| 2 | 65.10101-6021 | HOLDER;NOZZLE | 1 | ||
| 20 | 06.56180-0712 | RING;SEAL A8X14 | 14 | ||
| 21 | 65.12301-5022 | PIPE;FUEL(RETURN) | 1 | ||
| 21-1 | 65.12301-5818 | PIPE;FUEL(RETURN) | 1 | ||
| 21-2 | 65.10301-6289 | PRESSURE PIPE ASS'Y | 1 | ||
| 22 | 65.10301-5275 | PIPE;INJECTION(1 CYLINDER) | 1 | ||
| 23 | 65.10301-5276 | PIPE;INJECTION(2 CYLINDER) | 1 | ||
| 24 | 65.10301-5277 | PIPE;INJECTION(3 CYLINDER) | 1 | ||
| 25 | 65.10301-5278 | PIPE;INJECTION(4 CYLINDER) | 1 | ||
| 26 | 65.10301-5279 | PIPE;INJECTION(5 CYLINDER) | 1 | ||
| 27 | 65.10301-5280 | PIPE;INJECTION(6 CYLINDER) | 1 | ||
| 28 | 65.97401-6008 | PIPE CLIP ASS'Y | 5 | ||
| 29 | 06.12172-9316 | NUT;CAP M14X1.5 | 1 | ||
| 3 | 65.10102-6044 | NOZZLE | 1 | ||
| 30 | 65.96507-0010 | RING;SEAL | 2 | ||
| 31 | 65.11120-5001 | OVER FLOW VALVE ASS'Y | 1 | ||
| 32 | 65.96507-0010 | RING;SEAL | 1 | ||
| 33 | 65.05701-5200 | PIPE;OIL | 1 | ||
| 34 | 65.98155-0011 | UNION;HOLLOW | 1 | ||
| 35 | 06.12172-9314 | NUT;CAP | 1 | ||
| 36 | 06.56180-0714 | RING;SEAL | 2 | ||
| 37 | 65.08301-6008 | HOSE;AIR | 1 | ||
| 38 | 06.67020-0101 | CLAMP;HOSE | 1 | ||
| 39 | 65.98131-0050 | CONN SCREW | 1 | ||
| 40 | 06.56180-0714 | RING;SEAL | 3 | ||
| 41 | 65.11101-7275 | Насос | 1 |
65.11101-7655
|
|
| 41 | 65.11101-7292 | Насос | 1 |
65.11101-7655
|
|
| 41 | 65.11101-7655 | Насос | 1 | ||
| 41A | 105220-6410 | FEED PUMP | 1 | ||
| 41B | 31151-322S | PLUNGER | 6 | ||
| 41C | 65.11108-0010 | VALVE;DELIVERY | 1 | ||
| 41E | 156636-9020 | Муфта соединительная | 1 | ||
| 5 | 65.96507-0004 | RING;SEAL | 6 | ||
| 6 | 65.96507-0011 | RING;SEAL | 6 |
65.96507-0046
|
|
| 6 | 65.96507-0046 | RING;SEAL | 6 | ||
| 8 | 06.11063-8214 | Гайка М8 | 12 | ||
| 9 | 06.16731-2107 | Шайба пружинная | 12 |
