Каталог запчастей
-
Doosan
-
TXC140LC-2
- SEAT - HEATER
SEAT - HEATER экскаватора модели 2 Doosan TXC140LC-2
SEAT - HEATER экскаватора модели 2 Doosan TXC140LC-2 со списком деталей и комплектацией. Каждую деталь можно приобрести в наличии и под заказ с дотавкой по всей России
Код подсистемы:6110
Наименование:SEAT - HEATER
Версия:K1027953EF-1
SEAT - HEATER TXC140LC-2
| Поз. | Код | Наименование | Кол | Прим. | |
|---|---|---|---|---|---|
| - | 901-00047 | SEAT ASS'Y | 1 | ||
| 1 | K9001200 | UPPER ASS'Y | 1 | ||
| 10 | K9001208 | HEIGHT RISER | 1 | ||
| 11 | K9001209 | HEIGHT RISER SPRING KIT | 1 | ||
| 12 | K9001673 | LEVER/CENTRE PIVOT KIT | 1 | ||
| 13 | K9001674 | Комплект подшипника | 1 | ||
| 14 | K9001675 | AIR SPRING KIT | 1 | ||
| 15 | K9001213 | UPSTOP/BUMPSTOP KIT | 1 | ||
| 16 | K9001676 | DAMPER KIT | 1 | ||
| 17 | K9001677 | SUSPENSION ASS'Y | 1 | ||
| 18 | K9001678 | SUSPENSION COVER | 1 | ||
| 19 | K9001217 | SLIDING RAIL ASS'Y | 1 | ||
| 2 | K9001201 | BACK COVER | 1 | ||
| 20 | K9001218 | BELT;SEAT | 1 | ||
| 21 | K9001219 | HEAD REST | 1 | ||
| 22 | K9001220 | ARM REST-L.H | 1 | ||
| 23 | K9001221 | ARM REST-R.H | 1 | ||
| 24 | K9001223 | HEATER ASS'Y | 1 | ||
| 25 | K9001679 | HARNESS ASS'Y | 1 | ||
| 26 | K9001680 | COMPRESSOR KIT | 1 | ||
| 27 | K9001681 | AIR VALVE KIT | 1 | ||
| 28 | K9001682 | PIPE KIT | 1 | ||
| 3 | K9001202 | BACK FOAM | 1 | ||
| 4 | K9001203 | SEAT COVER | 1 | ||
| 5 | K9001204 | SEAT FOAM | 1 | ||
| 6 | K9001205 | FRAME | 1 | ||
| 7 | K9001206 | LUMBAR KIT | 1 | ||
| 8 | K9001207 | CABLE;ADJUST | 1 | ||
| 9 | 2.172-00003 | HANDLE | 1 |
