Каталог запчастей
-
Doosan
-
SOLAR 010
- GOVERNOR
GOVERNOR экскаватора гусеничного модели мини Doosan SOLAR 010
GOVERNOR экскаватора гусеничного модели мини Doosan SOLAR 010 со списком деталей и комплектацией. Каждую деталь можно приобрести в наличии и под заказ с дотавкой по всей России
Код подсистемы:210
Наименование:GOVERNOR
Версия:2021-7144EF
GOVERNOR SOLAR 010
| Поз. | Код | Наименование | Кол | Прим. | |
|---|---|---|---|---|---|
| 1 | 194990-22050 | WASHER;NUT | 1 | ||
| 10 | 119660-61341 | SLEEVE;GOVERNOR | 1 | ||
| 100 | 26116-060304 | BOLT M6X30 | 1 | ||
| 101 | 26756-060002 | NUT;LOCK M6 | 1 | ||
| 102 | 22190-060003 | WASHER;SEAL | 2 | ||
| 103 | 22190-120002 | WASHER;SEAL | 2 | ||
| 104 | 124250-03640 | SCREW;STOP | 1 | ||
| 11 | 119285-61120 | LINK L88.8 | 1 | ||
| 12 | 119285-61130 | LINK L88.6 | 1 | ||
| 13 | 119285-61140 | LINK L89.0 | 1 | ||
| 14 | 119285-61200 | GOVERNOR CASE ASS'Y | 1 | ||
| 15 | 129155-51280 | O-RING S6 | 1 | ||
| 16 | 119660-61013 | CASE;GOVERNOR | 1 | ||
| 17 | 119660-61052 | Прокладка | 1 | ||
| 18 | 119660-61460 | SHIM SET | 1 | ||
| 19 | 119660-61470 | SHIM T=0.1 | 2 | ||
| 2 | 119660-61060 | COVER;GOVERNOR CASE | 1 | ||
| 20 | 119660-61480 | SHIM T=0.2 | 2 | ||
| 21 | 129155-61480 | SPACER ASS'Y | 2 | ||
| 22 | 129156-61460 | SPACER T=0.6 | 2 | ||
| 23 | 129156-61470 | SPACER T=0.7 | 2 | ||
| 24 | 129156-61480 | SPACER T=1.2 | 2 | ||
| 25 | 129156-61490 | SPACER T=0.8 | 2 | ||
| 26 | 119660-61491 | SHAFT;GOVERNOR | 1 | ||
| 27 | 119285-61500 | GOVERNOR LEVER ASS'Y | 1 | ||
| 28 | 174307-51700 | SHIM SET | 2 | ||
| 29 | 174307-51710 | SHIM 0.1mm | 2 | ||
| 3 | 119660-61071 | Прокладка | 1 | ||
| 30 | 174307-51720 | SHIM 0.2mm | 2 | ||
| 31 | 174307-51730 | SHIM 0.3mm | 2 | ||
| 32 | 174307-51740 | SHIM 0.15mm | 2 | ||
| 33 | 174307-51750 | SHIM 0.05mm | 2 | ||
| 34 | 174307-51760 | SHIM 0.25mm | 2 | ||
| 35 | 174307-51770 | SHIM 0.35mm | 2 | ||
| 36 | 174307-51780 | SHIM 0.40mm | 2 | ||
| 37 | 174307-51790 | SHIM 0.45mm | 2 | ||
| 38 | 174307-51800 | SHIM 0.50mm | 2 | ||
| 39 | 119660-61512 | LEVER;TENSION | 1 | ||
| 4 | 119600-61100 | DRIVING SET;GOV. | 1 | ||
| 40 | 119600-61520 | LEVER;GOVERNOR | 1 | ||
| 41 | 121450-61520 | BEARING;NEEDLE | 2 | ||
| 42 | 119600-61541 | SHIFTER;P.T.O | 1 | ||
| 43 | 119600-61650 | SPRING;STARTING | 1 | ||
| 44 | 22117-040000 | WASHER M4 | 2 | ||
| 45 | 22272-000040 | Кольцо стопорное | 1 | ||
| 46 | 22351-030014 | PIN;SPRING | 1 | ||
| 47 | 119600-61900 | RETAINER;SHAFT | 1 | ||
| 48 | 119660-61901 | RETAINER;SHAFT | 1 | ||
| 49 | 119285-66090 | REGULATOR SHAFT ASS'Y | 1 | ||
| 5 | 119600-61200 | WEIGHT ASS'Y;GOV. | 1 | ||
| 50 | 119285-66060 | SHAFT;REGULATOR | 1 | ||
| 51 | 119285-66071 | LEVER;REGULATOR | 1 | ||
| 52 | 22322-030160 | PIN;TAPER | 1 | ||
| 53 | 22351-040010 | PIN;SPRING | 2 | ||
| 54 | 24341-000070 | Кольцо уплотнительное (О-кольцо) | 1 | ||
| 55 | 26106-060102 | BOLT M6X10 | 2 | ||
| 56 | 119640-61400 | Пробка (заглушка) | 1 | ||
| 57 | 119840-61870 | Пружина | 1 | ||
| 58 | 129100-61930 | NUT;CAP | 1 | ||
| 59 | 119600-66020 | SPRING;REGULATOR | 1 | ||
| 6 | 119600-61210 | WEIGHT;GOVERNOR | 3 | ||
| 60 | 119640-66051 | HANDLE;REGULATOR | 1 | ||
| 61 | 124550-66370 | NUT;LOCK M6 | 1 | ||
| 62 | 119600-66530 | TORQUE SPRING ASS'Y | 1 | ||
| 63 | 129100-61460 | PIN;CONTROLLER | 1 | ||
| 64 | 119600-66560 | BODY;CONTROLLER | 1 | ||
| 65 | 119600-66590 | Пружина | 1 | ||
| 66 | 124950-66590 | SHIM SET | 1 | ||
| 67 | 26756-050002 | NUT;LOCK M5 | 2 | ||
| 68 | 119654-66700 | ANGLEICH ASS'Y | 1 | ||
| 69 | 129155-61570 | CASE;ANGLEICH | 1 | ||
| 7 | 119660-61220 | PIN;GOVERNOR WEIGHT | 3 | ||
| 70 | 129155-61580 | SHIFTER;ANGLEICH | 1 | ||
| 71 | 129155-61590 | Гайка | 1 | ||
| 72 | 129156-61600 | SPRING;ANGLEICH | 1 | ||
| 73 | 129555-61800 | SHIM SET | 1 | ||
| 74 | 112100-51630 | SHIM;FUEL CONTROL | 1 | ||
| 75 | 112100-51640 | Прокладка | 1 | ||
| 76 | 112100-51650 | SHIM;FUEL CONTROL | 1 | ||
| 77 | 129555-61810 | SHIM T=0.6 | 1 | ||
| 78 | 129555-61820 | SHIM T=0.65 | 1 | ||
| 79 | 129555-61830 | SHIM T=0.7 | 1 | ||
| 8 | 119660-61291 | SUPPORT;GOV. WEIGHT | 1 | ||
| 80 | 129555-61840 | SHIM T=0.75 | 1 | ||
| 81 | 129555-61850 | SHIM T=0.8 | 1 | ||
| 82 | 129555-61860 | SHIM T=0.85 | 1 | ||
| 83 | 129555-61870 | SHIM T=0.9 | 1 | ||
| 84 | 129555-61880 | SHIM T=0.95 | 1 | ||
| 85 | 129555-61890 | SHIM T=1.0 | 1 | ||
| 86 | 129555-61900 | SHIM T=1.05 | 1 | ||
| 87 | 129555-61910 | SHIM T=1.1 | 1 | ||
| 88 | 129555-61920 | SHIM T=1.15 | 1 | ||
| 89 | 129555-61930 | SHIM T=1.2 | 1 | ||
| 9 | 119660-61300 | NUT;GOVERNOR WEIGHT | 1 | ||
| 90 | 22117-050000 | Шайба | 1 | ||
| 91 | 22272-000040 | Кольцо стопорное | 1 | ||
| 92 | 26776-120002 | NUT;LOCK M12 | 1 | ||
| 93 | 171002-66830 | SCREW;ADJUST | 1 | ||
| 94 | 119600-66840 | NUT;CAP | 1 | ||
| 95 | 119656-66910 | HOOK | 1 | ||
| 96 | 22360-040000 | PIN;SNAP | 1 | ||
| 97 | 22360-060000 | PIN;SNAP | 1 | ||
| 98 | 26106-060702 | BOLT M6X70 | 6 | ||
| 99 | 26116-050102 | BOLT M5X10 | 3 |
