TIMING GEAR CASE экскаватора колесного модели V Doosan SOLAR 130W-V
TIMING GEAR CASE экскаватора колесного модели V Doosan SOLAR 130W-V со списком деталей и комплектацией. Каждую деталь можно приобрести в наличии и под заказ с дотавкой по всей России
Код подсистемы:002
Наименование:TIMING GEAR CASE
Версия:2021-7135EF
TIMING GEAR CASE SOLAR 130W-V
| Поз. | Код | Наименование | Кол | Прим. | |
|---|---|---|---|---|---|
| 1 | 65.01304-0016 | CASE;TIMING GEAR | 1 | ||
| 10 | 65.01304-0003C | CASE;TIMING GEAR | 1 | ||
| 10 | 65.01307-0002 | COVER;TIMING CHECK HOLE | 2 |
65.01307-0002B
|
|
| 10 | 65.01307-0002B | COVER;TIMING CHECK HOLE | 2 | ||
| 100 | 06.01913-3122 | BOLT ASS'Y M8X55 | 5 | ||
| 11 | 06.01913-2911 | BOLT ASS'Y M6X16 | 4 | ||
| 110 | 65.01307-0002B | COVER;TIMING CHECK HOLE | 2 | ||
| 12 | 65.01510-0001 | SEAL;OIL(FRONT) | 1 | ||
| 120 | 65.01903-0002C | Прокладка | 2 | ||
| 13 | 65.01903-0002C | Прокладка | 2 | ||
| 13 | 65.01903B0002 | GASKET(T.G.C) | 2 |
65.01903-0002C
|
|
| 130 | 06.01913-2911 | BOLT ASS'Y M6X16 | 4 | ||
| 14 | 65.01903A0026 | GASKET;COVER(T.G.C) | 1 | ||
| 140 | 65.01510-0001 | SEAL;OIL(FRONT) | 1 | ||
| 15 | 65.01903B0004 | GASKET;TIMING GEAR CASE(BLOCK) | 1 | ||
| 16 | 65.01307-0008 | COVER;GEAR CASE P.T.O | 1 | ||
| 17 | 06.06125-8702 | BOLT;STUD M8X16 | 1 | ||
| 18 | 06.11063-8214 | Гайка М8 | 1 | ||
| 19 | 06.01913-3111 | Болт в сборе (с шайбой и гровером) | 3 | ||
| 2 | 06.22022-3119 | Палец | 1 | ||
| 20 | 06.22022-3119 | Палец | 1 | ||
| 20 | 06.16731-2107 | Шайба пружинная | 1 | ||
| 21 | 65.01903A0020 | GASKET;COVER | 1 | ||
| 22 | 65.38502-0012 | GEAR;IDLE P.T.O | 1 | ||
| 23 | 65.38502-0005 | GEAR P.T.O | 1 | ||
| 24 | 06.31410-1616 | BEARING;BALL | 4 | ||
| 25 | 65.38525-0005 | CASE;GEAR | 1 | ||
| 26 | 06.06175-8305 | BOLT;STUD M12X1.5X22 | 2 | ||
| 27 | 06.01913-3112 | BOLT ASS'Y M8X18 | 4 | ||
| 28 | 06.01913-3123 | BOLT;HEX. M8X60 | 2 | ||
| 29 | 06.01913-3116 | BOLT;HEX. M8X28 | 1 | ||
| 3 | 06.01913-3113 | BOLT ASS'Y M8X20 | 4 | ||
| 30 | 65.38520-0003 | ADAPTER;P.T.O PUMP | 1 | ||
| 30 | 65.01903B0004 | GASKET;TIMING GEAR CASE(BLOCK) | 1 | ||
| 31 | 06.06226-0806 | Болт-шпилька | 2 | ||
| 32 | 06.11024-9203 | NUT;HEX. M12X1.5 | 2 | ||
| 33 | 06.16731-2109 | Шайба пружинная A12 | 2 | ||
| 34 | 65.38525-0001 | COVER;ADAPTER | 1 | ||
| 35 | 06.11063-8215 | NUT;HEX. M10 | 2 | ||
| 36 | 06.16731-2108 | Шайба пружинная | 2 | ||
| 37 | 65.38901A0001 | GASKET;PTO COVER | 1 | ||
| 38 | 65.38901-0014 | GASKET;COVER | 1 | ||
| 39 | 65.38901-0003 | GASKET;COVER | 1 | ||
| 39 | 65.38901A0003 | GASKET;COVER | 1 |
65.38901-0003
|
|
| 4 | 65.01305-0017 | COVER;TIMING GEAR CASE | 1 | ||
| 40 | 06.01913-3113 | BOLT ASS'Y M8X20 | 4 | ||
| 40 | 65.91301-0002A | POINTER | 1 | ||
| 41 | 65.05701-5143 | OIL PIPE ASS'Y | 1 | ||
| 42 | 65.05401-5017 | Клапан обратный, в сборе | 1 | ||
| 43 | 06.56180-0714 | RING;SEAL | 2 | ||
| 44 | 65.98150-0056 | SCREW;HOLLOW | 1 | ||
| 45 | 06.56180-0712 | RING;SEAL A8X14 | 2 | ||
| 46 | 65.91730-0014 | Вставка | 1 | ||
| 47 | 06.01943-3219 | BOLT;HEX. M10X1.25X40 | 1 | ||
| 5 | 06.22022-3111 | Палец | 1 | ||
| 50 | 06.01913-3120 | BOLT ASS'Y M8X45 | 2 | ||
| 6 | 06.01913-3123 | BOLT;HEX. M8X60 | 3 | ||
| 60 | 65.01305-5074 | COVER;TIMING GEAR CASE | 1 | ||
| 7 | 06.01913-3124 | BOLT ASS'Y M8X65 | 3 | ||
| 70 | 06.22022-3111 | Палец | 1 | ||
| 8 | 06.01913-3117 | BOLT ASS'Y M8X30 | 3 | ||
| 80 | 65.01903B0003 | GASKET(T.G.C) | 1 | ||
| 9 | 06.01913-3118 | BOLT ASS'Y M8X35 | 1 | ||
| 90 | 06.01913-3115 | BOLT ASS'Y M8X25 | 7 |
