Каталог запчастей
-
Doosan
-
SOLAR 55W-V SUPER
- ENGINE CONTORL ASS’Y
ENGINE CONTORL ASS’Y экскаватора колесного модели V Doosan SOLAR 55W-V SUPER
ENGINE CONTORL ASS’Y экскаватора колесного модели V Doosan SOLAR 55W-V SUPER со списком деталей и комплектацией. Каждую деталь можно приобрести в наличии и под заказ с дотавкой по всей России
Код подсистемы:1330
Наименование:ENGINE CONTORL ASS’Y
Версия:021-00035EF
ENGINE CONTORL ASS’Y SOLAR 55W-V SUPER
| Поз. | Код | Наименование | Кол | Прим. | |
|---|---|---|---|---|---|
| - | 133-00179 | ENGINE CONTORL ASS'Y | - | ||
| - | 133-00179 | ENGINE CONTORL ASS'Y | - | ||
| - | 133-00205 | ENGINE CONTORL ASS'Y | - | ||
| - | 133-00205 | ENGINE CONTORL ASS'Y | - | ||
| 1 | 195-01257E | BRACKET;ACCEL | 1 | ||
| 1 | 195-01257E | BRACKET;ACCEL | 1 | ||
| 10 | S4210733 | NUT;CASTLE | 1 | ||
| 10 | S4210733 | NUT;CASTLE | 1 | ||
| 11 | 132-00021 | GRIP | 1 | ||
| 11 | 132-00021 | GRIP | 1 | ||
| 12 | 195-02433A | BRACKET;E/G CONTROL | 1 | ||
| 12 | 195-02433A | BRACKET;E/G CONTROL | 1 | ||
| 12 | 195-02433B | BRACKET;E/G CONTROL | 1 | ||
| 12 | 195-02433B | BRACKET;E/G CONTROL | 1 | ||
| 13 | 2160-1332 | BOOT | 1 | ||
| 13 | 2160-1332 | BOOT | 1 | ||
| 14 | S0511553 | BOLT M10X1.5X14 | 2 | ||
| 14 | S0511553 | BOLT M10X1.5X14 | 2 | ||
| 16 | 2123-2385A | Палец | 1 | ||
| 16 | 2123-2385A | Палец | 1 | ||
| 17 | S5735481 | PIN;SPLIT | 1 | ||
| 17 | S5735481 | PIN;SPLIT | 1 | ||
| 18 | 2135-1008D39 | Вилка | 1 | ||
| 18 | 2135-1008D39 | Вилка | 1 | ||
| 19 | S5760142 | PIN;FLANGE | 1 | ||
| 19 | S5760142 | PIN;FLANGE | 1 | ||
| 2 | S0511853 | BOLT M10X1.5X20 | 2 | ||
| 2 | S0511853 | Болт | 2 | ||
| 2 | S0511853 | BOLT M10X1.5X20 | 2 | ||
| 2 | S0511853 | Болт | 2 | ||
| 20 | 2123-1441D1 | PIN;SET | 1 | ||
| 20 | 2123-1441D1 | PIN;SET | 1 | ||
| 21 | S5010513 | WASHER;PLAIN M8 | 2 | ||
| 21 | S5010513 | WASHER;PLAIN M8 | 2 | ||
| 22 | S5102503 | Шайба пружинная M8 | 1 | ||
| 22 | S5102503 | Шайба пружинная M8 | 1 | ||
| 23 | S0556253 | BOLT M8X1.25X45 | 1 | ||
| 23 | S0556253 | BOLT M8X1.25X45 | 1 | ||
| 24 | 136-00049 | ROD;PEDAL VALVE | 1 | ||
| 24 | 136-00049 | ROD;PEDAL VALVE | 1 | ||
| 25 | S4012333 | NUT M6X1.0 | 3 | ||
| 25 | S4012333 | NUT M6X1.0 | 3 | ||
| 26 | 2135-1008D3 | END;FORK | 1 | ||
| 26 | 2135-1008D3 | END;FORK | 1 | ||
| 27 | 2123-1888 | Палец | 3 | ||
| 27 | 2123-1888 | Палец | 3 | ||
| 28 | S5010313 | WASHER;PLAIN M6 | 4 | ||
| 28 | S5010313 | WASHER;PLAIN M6 | 4 | ||
| 29 | S5735121 | PIN;SPLIT | 3 | ||
| 29 | S5735121 | PIN;SPLIT | 3 | ||
| 3 | S5102603 | Шайба пружинная M10 | 4 | ||
| 3 | S5102603 | Шайба пружинная M10 | 4 | ||
| 30 | 2133-2071A | LEVER | 1 | ||
| 30 | 2133-2071A | LEVER | 1 | ||
| 31 | S0558253 | BOLT M10X1.5X35 | 1 | ||
| 31 | S0558253 | BOLT M10X1.5X35 | 1 | ||
| 32 | S4012633 | NUT M10X1.5 | 3 | ||
| 32 | S4012633 | NUT M10X1.5 | 3 | ||
| 33 | 2123-1057D6 | Палец | 1 | ||
| 33 | 2123-1057D6 | Палец | 1 | ||
| 34 | S5735213 | PIN;SPLIT | 1 | ||
| 34 | S5735213 | PIN;SPLIT | 1 | ||
| 35 | 2135-1008D29 | END;FORK | 1 | ||
| 35 | 2135-1008D29 | END;FORK | 1 | ||
| 36 | 2129-1039 | Пружина | 1 | ||
| 36 | 2129-1039 | Пружина | 1 | ||
| 37 | 2136-1362 | Щуп | 1 | ||
| 37 | 2136-1362 | Щуп | 1 | ||
| 38 | 2109-9019 | BEARING;NEEDLE | 2 | ||
| 38 | 2109-9019 | BEARING;NEEDLE | 2 | ||
| 39 | 2139-1030D11 | CABLE;CONTROL | 1 | ||
| 39 | 2139-1030D11 | CABLE;CONTROL | 1 | ||
| 4 | S0508853 | BOLT M8X1.25X20 | 2 | ||
| 4 | S0508853 | BOLT M8X1.25X20 | 2 | ||
| 40 | 133-00177 | LEVER | 1 | ||
| 40 | 133-00177 | LEVER | 1 | ||
| 41 | 2120-2145 | BOLT M6X1.0X20 | 2 | ||
| 41 | 2120-2145 | BOLT M6X1.0X20 | 2 | ||
| 43 | S5102303 | Шайба пружинная M6 | 2 | ||
| 43 | S5102303 | Шайба пружинная M6 | 2 | ||
| 44 | 2110-1184D27 | BUSH;DU | 3 | ||
| 44 | 2110-1184D27 | BUSH;DU | 3 | ||
| 45 | 133-00176 | LEVER | 1 | ||
| 45 | 133-00176 | LEVER | 1 | ||
| 46 | 133-00175 | LEVER | 2 | ||
| 46 | 133-00175 | LEVER | 2 | ||
| 47 | 2114-1699 | Шайба | 2 | ||
| 47 | 2114-1699 | Шайба | 2 | ||
| 48 | 2123-2315 | Палец | 1 | ||
| 48 | 2123-2315 | Палец | 1 | ||
| 49 | S5735471 | PIN;SPLIT | 1 | ||
| 49 | S5735471 | PIN;SPLIT | 1 | ||
| 5 | S4012533 | NUT M8X1.25 | 2 | ||
| 5 | S4012533 | NUT M8X1.25 | 2 | ||
| 50 | S5010913 | WASHER;PLAIN M16 | 1 | ||
| 50 | S5010913 | WASHER;PLAIN M16 | 1 | ||
| 51 | 2135-1008D25 | END;FORK | 2 | ||
| 51 | 2135-1008D25 | END;FORK | 2 | ||
| 6 | 139-00040 | CABLE;ACCEL. | 1 | ||
| 6 | 139-00040 | CABLE;ACCEL. | 1 | ||
| 7 | 133-00128A | LEVER | 1 | ||
| 7 | 133-00128A | LEVER | 1 | ||
| 8 | S5130703 | Шайба пружинная | 4 | ||
| 8 | S5130703 | Шайба пружинная | 4 | ||
| 9 | 2114-1058D72 | Шайба плоская | 4 | ||
| 9 | 2114-1058D72 | Шайба плоская | 4 |
