TIMING GEAR CASE экскаватора модели 1 Doosan TXC 470LC-1
TIMING GEAR CASE экскаватора модели 1 Doosan TXC 470LC-1 со списком деталей и комплектацией. Каждую деталь можно приобрести в наличии и под заказ с дотавкой по всей России
Код подсистемы:002
Наименование:TIMING GEAR CASE
Версия:021-00076EF
TIMING GEAR CASE TXC 470LC-1
| Поз. | Код | Наименование | Кол | Прим. | |
|---|---|---|---|---|---|
| 1 | 65.01304-0023C | CASE;TIMING GEAR | 1 | ||
| 1 | 65.01304-0023C | CASE;TIMING GEAR | 1 | ||
| 10 | 06.01923-2917 | BOLT ASS'Y M6X30 | 7 | ||
| 10 | 06.01923-2917 | BOLT ASS'Y M6X30 | 7 | ||
| 11 | 06.01953-3326 | BOLT ASS'Y M12X1.5X75 | 3 | ||
| 11 | 06.01953-3326 | BOLT ASS'Y M12X1.5X75 | 3 | ||
| 12 | 65.01510-0157 | SEAL;OIL | 1 | ||
| 12 | 65.01510-0157 | SEAL;OIL | 1 | ||
| 2 | 65.91010-0017 | PIN;DOWEL M6X60 | 2 | ||
| 2 | 65.91010-0017 | PIN;DOWEL M6X60 | 2 | ||
| 21 | 65.91601-0010 | Крышка | 1 | ||
| 21 | 65.91601-0010 | Крышка | 1 | ||
| 22 | 65.47901-0010 | GASKET;P/S PUMP | 1 | ||
| 22 | 65.47901-0010 | GASKET;P/S PUMP | 1 | ||
| 23 | 06.01913-3219 | BOLT ASS'Y M10X40 | 2 | ||
| 23 | 06.01913-3219 | BOLT ASS'Y M10X40 | 2 | ||
| 24 | 06.01013-9221 | BOLT;HEX. M10X80 | 1 | ||
| 24 | 06.01013-9221 | BOLT;HEX. M10X80 | 1 | ||
| 25 | 06.16731-2108 | Шайба пружинная | 1 | ||
| 25 | 06.16731-2108 | Шайба пружинная | 1 | ||
| 3 | 65.01903-0048B | Прокладка | 1 | ||
| 3 | 65.01903-0048B | Прокладка | 1 | ||
| 31 | 65.91601-0003 | COVER;BLIND | 1 | ||
| 31 | 65.91601-0003 | COVER;BLIND | 1 | ||
| 31 | 65.91601-6003 | COVER;BLIND | 1 |
65.91601-6003A
|
|
| 31 | 65.91601-6003 | COVER;BLIND | 1 |
65.91601-6003A
|
|
| 31 | 65.91601-6003A | COVER;BLIND | 1 |
65.91601-6005
|
|
| 31 | 65.91601-6003A | COVER;BLIND | 1 |
65.91601-6005
|
|
| 31 | 65.91601-6005 | COVER;BLIND | 1 | ||
| 31 | 65.91601-6005 | COVER;BLIND | 1 | ||
| 32 | 06.01924-3217 | BOLT ASS'Y M10X30 | 4 | ||
| 32 | 06.01924-3217 | BOLT ASS'Y M10X30 | 4 | ||
| 33 | 65.54901-0025A | GASKET;AIR COMPRESSOR | 1 | ||
| 33 | 65.54901-0025A | GASKET;AIR COMPRESSOR | 1 | ||
| 34 | 65.05701-5361 | OIL PIPE ASS'Y | 1 | ||
| 34 | 65.05701-5361 | OIL PIPE ASS'Y | 1 | ||
| 38 | 65.98150-0056 | SCREW;HOLLOW | 1 | ||
| 38 | 65.98150-0056 | SCREW;HOLLOW | 1 | ||
| 39 | 06.56180-0712 | RING;SEAL A8X14 | 2 | ||
| 39 | 06.56180-0712 | RING;SEAL A8X14 | 2 | ||
| 4 | 06.01943-3317 | BOLT ASS'Y M12X1.5X30 | 3 | ||
| 4 | 06.01943-3317 | BOLT ASS'Y M12X1.5X30 | 3 | ||
| 5 | 06.01943-3320 | BOLT ASS'Y M12X1.5X45 | 5 | ||
| 5 | 06.01943-3320 | BOLT ASS'Y M12X1.5X45 | 5 | ||
| 6 | 06.01913-3215 | BOLT ASS'Y M10X25 | 1 | ||
| 6 | 06.01913-3215 | BOLT ASS'Y M10X25 | 1 | ||
| 7 | 65.01305-5049G | T.G.C. COVER ASS'Y | 1 | ||
| 7 | 65.01305-5049G | T.G.C. COVER ASS'Y | 1 | ||
| 8 | 65.01903-0050 | GASKET;T.G.C. COVER | 1 | ||
| 8 | 65.01903-0050 | GASKET;T.G.C. COVER | 1 | ||
| 9 | 06.01923-2914 | BOLT ASS'Y M6X22 | 6 | ||
| 9 | 06.01923-2914 | BOLT ASS'Y M6X22 | 6 |
