STEERING ASS'Y колесного погрузчика модели I Doosan DOZER
STEERING ASS'Y колесного погрузчика модели I Doosan DOZER со списком деталей и комплектацией. Каждую деталь можно приобрести в наличии и под заказ с дотавкой по всей России
Код подсистемы:1330
Наименование:STEERING ASS'Y
Версия:4021-7070EF
STEERING ASS'Y DOZER
| Поз. | Код | Наименование | Кол | Прим. | |
|---|---|---|---|---|---|
| - | 4305-4003 | STEERING SHAFT ASS'Y | - | ||
| 1 | 2154-9002 | WHEEL ASS'Y | 1 | ||
| 10 | 4303-1013A | COLUMN | 1 |
4303-1013B
|
|
| 10 | 4303-1013B | COLUMN | 1 | ||
| 11 | S6001240 | BEARING;BALL | 1 | ||
| 12 | S6510420 | Кольцо | 1 | ||
| 13 | S6500200 | Кольцо | 1 | ||
| 14 | 4135-9401 | U-JOINT ASS'Y | 1 | ||
| 15 | 4112-4012 | Вал | 1 | ||
| 16 | 4414-9406 | COUPLING;FLEXIBLE | 1 | ||
| 17 | 4120-4042 | BOLT 3/8"-18UNCX20 | 4 | ||
| 18 | 4161-9036 | MOUNT;FLEX | 4 | ||
| 18 | 4161-9409 | MOUNT;FLEXIBLE | 4 | ||
| 19 | 4195-4498 | Кронштейн | 1 |
4195-4498B
|
|
| 19 | 4195-4498B | Кронштейн | 1 | ||
| 1A | 2301-7004 | WHEEL | 1 | ||
| 1B | 2549-7013 | BUTTON;HORN | 1 | ||
| 1C | 2130-7001 | LOCK;SPRING | 1 | ||
| 1D | 2522-7007 | CUP | 1 | ||
| 1E | 2129-7003 | Пружина | 1 | ||
| 1F | 2132-7001 | GRIP ASS'Y | 1 | ||
| 1F1 | 2195-7026 | STAND | 1 | ||
| 1F2 | 2132-7002 | GRIP | 1 | ||
| 1F3 | 2120-7019 | Болт | 1 | ||
| 1F4 | 2116-7005 | Крышка | 1 | ||
| 1F5 | 2116-7006 | Пластина | 1 | ||
| 1F7 | S3450993 | SCREW M6X1.0X25 | 2 | ||
| 1F8 | S5100302 | Шайба пружинная M6 | 2 | ||
| 2 | S4032733 | Гайка | 1 | ||
| 20 | S5032603 | WASHER;PLAIN M10 | 4 | ||
| 21 | S5102603 | Шайба пружинная M10 | 4 | ||
| 22 | 4191-3260 | Пластина | 2 | ||
| 23 | 4161-4053 | PLATE;RUBBER | 1 | ||
| 24 | 4195-4484 | Вставка | 1 | ||
| 25 | S5011113 | Шайба плоская | 2 | ||
| 26 | 4120-4037 | BOLT M20X2.5X140 | 1 | ||
| 26 | 4120-4037A | Болт | 1 | ||
| 27 | 4191-4325 | Пластина | 1 | ||
| 28 | S0508453 | BOLT M8X1.25X12 | 1 | ||
| 28 | S0708453 | BOLT M8X1.0X12 | 1 | ||
| 29 | S5102503 | Шайба пружинная M8 | 1 | ||
| 3 | S5102703 | Шайба пружинная M12 | 1 | ||
| 30 | 4191-4324 | SEAT;SCREW M20X1.5/M10X1.25 | 1 | ||
| 30 | 4191-4324A | SEAT;SCREW | 1 | ||
| 31 | 4133-4074 | LEVER ASS'Y | 1 | ||
| 33 | 4110-4025 | Втулка | 2 |
4110-4025A
|
|
| 33 | 4110-4025A | Втулка | 2 | ||
| 34 | 4114-4066 | Шайба | 2 | ||
| 35 | 4120-4039 | BOLT M10X1.25X30 | 2 | ||
| 36 | S4220633 | NUT;CASTLE M10X1.25 | 2 | ||
| 37 | S5735401 | PIN;SNAP 2.5X35 | 2 | ||
| 38 | 4549-9418 | SWITCH;COLUMN | 1 | ||
| 39 | 4160-4018 | GAITER;FLEXIBLE | 1 | ||
| 4 | S0502953 | BOLT M5X0.8X12 | 14 | ||
| 40 | 4191-4322A | PLATE;COVER | 1 |
4191-4322B
|
|
| 40 | 4191-4322B | PLATE;COVER | 1 | ||
| 41 | 4191-4323A | PLATE;COVER | 1 |
4191-4323B
|
|
| 41 | 4191-4323B | PLATE;COVER | 1 | ||
| 43 | S5100203 | Шайба пружинная M5 | 6 | ||
| 45 | S0515053 | BOLT M12X1.75X25 | 4 | ||
| 46 | S5102703 | Шайба пружинная M12 | 4 | ||
| 47 | 2160-1004D21 | BUSHING;RUBBER | 1 | ||
| 48 | 2124-1024D9 | CLAMP;HOSE | 1 | ||
| 49 | S0512453 | BOLT M10X1.5X40 | 4 | ||
| 5 | 4146-4003A | STRIKER | 1 | ||
| 50 | 4160-1277 | BUSHING;RUBBER | 1 | ||
| 51 | 4191-4346A | Пластина | 1 | ||
| 52 | 4120-2113 | BOLT M6X1.0X37 | 3 | ||
| 53 | S5102303 | Шайба пружинная M6 | 3 | ||
| 54 | S4012333 | NUT M6X1.0 | 3 | ||
| 55 | 0501 209 270 | SELECTOR;RANGE | 1 | ||
| 6 | S3503833 | SCREW M6X1X10 | 2 | ||
| 7 | S6510350 | RING;RETAINER | 1 | ||
| 8 | 4109-9402 | BEARING;NEEDLE | 1 | ||
| 9 | 4112-4011 | Вал | 1 |
