Каталог запчастей
-
Doosan
-
MEGA400-V FACE LIFT
- DRIVING SYSTEM
DRIVING SYSTEM колесного погрузчика модели V Doosan MEGA400-V FACE LIFT
DRIVING SYSTEM колесного погрузчика модели V Doosan MEGA400-V FACE LIFT со списком деталей и комплектацией. Каждую деталь можно приобрести в наличии и под заказ с дотавкой по всей России
Код подсистемы:140
Наименование:DRIVING SYSTEM
Версия:021-00082EF
DRIVING SYSTEM MEGA400-V FACE LIFT
| Поз. | Код | Наименование | Кол | Прим. | |
|---|---|---|---|---|---|
| 1 | 65.02101-0057A | SHAFT;CRANK | 1 | ||
| 1 | 65.02101-0057B | SHAFT;CRANK | 1 | ||
| 10 | 65.01110-6115 | BEARING;MAIN | 7 | ||
| 10 | 65.01110-6116 | BEARING;MAIN 0.25 | 7 | ||
| 10 | 65.01110-6117 | BEARING;MAIN 0.50 | 7 | ||
| 11 | 65.01150-0017A | Шайба упорная | 2 | ||
| 11 | 65.01150-0048A | Шайба упорная 0.25 | 2 | ||
| 11 | 65.01150-0049A | Шайба упорная 0.5 | 2 | ||
| 12 | 65.01150-0018B | Шайба упорная | 2 | ||
| 12 | 65.01150-0052B | Шайба упорная 0.25 | 2 | ||
| 12 | 65.01150-0053B | Шайба упорная 0.5 | 2 | ||
| 13 | 65.02201-7032 | DAMPER;VIBRATION | 1 | ||
| 14 | 06.01914-3215 | BOLT ASS'Y M10X25 | 6 |
65.90020-0062B
|
|
| 14 | 65.90020-0062B | BOLT ASS'Y M10X20 | 6 | ||
| 15 | 65.02301-5102 | FLY WHEEL ASS'Y | 1 | ||
| 16 | 65.02301-0248 | FLY WHEEL | 1 | ||
| 17 | 65.02310-0011A | GEAR;STARTER RING | 1 | ||
| 18 | 06.22022-1010 | PIN;DOWEL | 1 | ||
| 19 | 65.90001-0164 | BOLT;HEX. M14X1.5X70 | 8 | ||
| 2 | 65.02101-0060A | Коленчатый вал в сборе | 1 | ||
| 2 | 65.02101-0060B | SHAFT;CRANK | 1 | ||
| 20 | 06.16731-2110 | Шайба пружинная | 8 | ||
| 21 | 65.02401-6017A | CONNECTING ROD ASS'Y | 6 |
65.02401-6017B
|
|
| 21 | 65.02401-6017B | CONNECTING ROD ASS'Y | 6 |
65.02401-6017C
|
|
| 21 | 65.02401-6017C | CONNECTING ROD ASS'Y | 6 | ||
| 22 | 65.02401-0045F | ROD;CONNECTING | 1 | ||
| 22 | 65.02401-0045G | ROD;CONNECTING | 1 | ||
| 23 | 65.90020-0010E | BOLT;CON-ROD | 2 | ||
| 24 | 65.02405-0011 | BUSH;CON-ROD | 1 | ||
| 24 | 65.02405-1010 | BUSH;CON-ROD | 1 |
65.02405-0011
|
|
| 25 | 65.91301-0010 | PIN;DOWEL | 2 | ||
| 26 | 65.02410-6106 | BEARING;CON-ROD | 6 | ||
| 26 | 65.02410-6107 | BEARING;CON-ROD 0.25 | 6 | ||
| 26 | 65.02410-6108 | BEARING;CON-ROD 0.50 | 6 | ||
| 26 | 65.02410-6109 | BEARING;CON-ROD 0.75 | 6 | ||
| 27 | 65.02501-0601 | Поршень | 6 |
65.02501-0601A
|
|
| 27 | 65.02501-0601A | Поршень | 6 |
65.02501-0601B
|
|
| 27 | 65.02501-0601B | Поршень | 6 | ||
| 28 | 65.02503-0674 | RING;TOP | 6 | ||
| 29 | 65.02503-0097 | RING;2ND | 6 | ||
| 3 | 65.02101-0054A | SHAFT;CRANK | 1 | ||
| 30 | 65.02503-0675B | RING;OIL | 6 | ||
| 31 | 65.02502-0013 | PIN;PISTON | 6 | ||
| 32 | 06.29020-0127 | RING;SNAP 45X1.75 | 12 | ||
| 33 | 65.02601-0180 | PULLEY;V-BELT | 1 | ||
| 34 | 65.90701-0088 | Шайба | 1 | ||
| 35 | 06.02106-0622 | BOLT;SOCKET HEAD | 8 | ||
| 4 | 65.02110-0013E | WEIGHT;COUNTER | 4 | ||
| 5 | 65.02110-0014E | WEIGHT;COUNTER | 4 | ||
| 6 | 65.90430-0012B | BOLT;CRANK SHAFT | 8 | ||
| 7 | 65.90430-0013B | BOLT;CRANK SHAFT | 8 | ||
| 8 | 65.02115-0008B | GEAR;CRANK SHAFT | 1 | ||
| 9 | 06.22022-0912 | PIN;DOWEL | 1 | ||
| A | 65.02101-7541B | CRANKSHAFT ASS'Y | 1 |
65.02101-7541C
|
|
| A | 65.02101-7541C | CRANKSHAFT ASS'Y | 1 |
