Каталог запчастей
-
Doosan
-
MEGA400-V FACE LIFT
- POWER TAKE-OFF(1)-TRANSMISSION
POWER TAKE-OFF(1)-TRANSMISSION колесного погрузчика модели V Doosan MEGA400-V FACE LIFT
POWER TAKE-OFF(1)-TRANSMISSION колесного погрузчика модели V Doosan MEGA400-V FACE LIFT со списком деталей и комплектацией. Каждую деталь можно приобрести в наличии и под заказ с дотавкой по всей России
Код подсистемы:3190
Наименование:POWER TAKE-OFF(1)-TRANSMISSION
Версия:021-00082EF
POWER TAKE-OFF(1)-TRANSMISSION MEGA400-V FACE LIFT
| Поз. | Код | Наименование | Кол | Прим. | |
|---|---|---|---|---|---|
| - | K9000142 | POWER TAKE-OFF(1) | 1 | ||
| 10 | 2.405-00215 | Вал | 1 | ||
| 100 | 2.120-00599 | Болт | 8 | ||
| 112 | 2.180-00284 | Кольцо уплотнительное (О-кольцо) | 1 | ||
| 120 | 2.403-00006 | GEAR | 1 | ||
| 130 | 1.115-00030 | RING;RETAINING | 1 | ||
| 140 | K9000114 | BEARING;ROLLER | 1 | ||
| 20 | 2.115-00245 | RING;PISTON | 1 | ||
| 24 | 2.109-00206 | BEARING;ROLLER | 1 | ||
| 28 | 1.114-00057 | SHIM A=1.95 | 1 | ||
| 28 | 1.114-00060 | SHIM A=0.1 | 1 | ||
| 28 | 1.114-00061 | SHIM A=0.15 | 1 | ||
| 28 | 1.114-00063 | SHIM A=0.25 | 1 | ||
| 28 | 1.114-00065 | SHIM A=0.3 | 1 | ||
| 28 | 1.114-00066 | SHIM A=0.35 | 1 | ||
| 28 | 1.114-00068 | SHIM A=0.65 | 1 | ||
| 28 | 1.114-00069 | SHIM A=0.70 | 1 | ||
| 28 | 1.114-00070 | SHIM A=0.75 | 1 | ||
| 28 | 1.114-00071 | SHIM A=0.85 | 1 | ||
| 28 | 1.114-00073 | SHIM A=0.90 | 1 | ||
| 28 | 1.114-00074 | SHIM A=0.95 | 1 | ||
| 28 | 1.114-00079 | SHIM A=1.05 | 1 | ||
| 28 | 1.114-00083 | SHIM A=1.10 | 1 | ||
| 28 | 1.114-00085 | SHIM A=1.15 | 1 | ||
| 28 | 1.114-00091 | SHIM A=1.25 | 1 | ||
| 28 | 1.114-00095 | SHIM A=1.30 | 1 | ||
| 28 | 1.114-00097 | SHIM A=1.35 | 1 | ||
| 28 | 1.114-00101 | SHIM A=1.4 | 1 | ||
| 28 | 1.114-00103 | SHIM A=1.45 | 1 | ||
| 28 | 1.114-00108 | SHIM A=1.50 | 1 | ||
| 28 | 1.114-00110 | SHIM A=1.55 | 1 | ||
| 28 | 1.114-00113 | SHIM A=1.60 | 1 | ||
| 28 | 1.114-00114 | SHIM A=1.65 | 1 | ||
| 28 | 1.114-00125 | SHIM A=2.00 | 1 | ||
| 28 | 1.114-00198 | SHIM A=1.47 | 1 | ||
| 28 | 1.114-00202 | SHIM A=1.63 | 1 | ||
| 28 | 1.114-00203 | SHIM A=1.70 | 1 | ||
| 28 | 1.114-00204 | SHIM A=1.75 | 1 | ||
| 28 | 1.114-00207 | SHIM A=1.80 | 1 | ||
| 28 | 1.114-00208 | SHIM A=1.85 | 1 | ||
| 28 | 1.114-00209 | SHIM A=1.90 | 1 | ||
| 28 | 2.114-00571 | SHIM A=0.2 | 1 | ||
| 28 | 2.114-00572 | SHIM A=0.4 | 1 | ||
| 28 | 2.114-00573 | SHIM A=0.45 | 1 | ||
| 28 | 2.114-00574 | SHIM A=0.5 | 1 | ||
| 28 | 2.114-00575 | SHIM A=0.55 | 1 | ||
| 28 | 2.114-00576 | SHIM A=0.6 | 1 | ||
| 28 | 2.114-00577 | SHIM A=0.8 | 1 | ||
| 28 | 2.114-00579 | SHIM A=1.0 | 1 | ||
| 28 | 2.114-00580 | SHIM A=1.2 | 1 | ||
| 34 | K9000085 | WASHER A=2.00 | 1 | ||
| 40 | 2.211-00007 | DRIVER | 1 | ||
| 50 | 2.180-01064 | RING;V | 1 | ||
| 60 | 2.412-00283 | Пластина | 1 | ||
| 70 | 2.120-00551 | Болт | 1 | ||
| 80 | 2.180-00349 | Кольцо уплотнительное (О-кольцо) | 1 | ||
| 90 | 2.181-00078 | FLANGE;PUMP | 1 |
