Каталог запчастей
-
Hyundai
-
HBF15/18T
- FREE LIFT CYLINDER(3 STAGE)
FREE LIFT CYLINDER(3 STAGE) погрузчика электрического Hyundai HBF15/18T
FREE LIFT CYLINDER(3 STAGE) погрузчика электрического Hyundai HBF15/18T со списком деталей и комплектацией. Каждую деталь можно приобрести в наличии и под заказ с дотавкой по всей России
Код подсистемы:7180
Наименование:FREE LIFT CYLINDER(3 STAGE)
Версия:2001.12.12 REV.2
FREE LIFT CYLINDER(3 STAGE) HBF15/18T
| Поз. | Код | Наименование | Кол | Прим. | |
|---|---|---|---|---|---|
| * | B512520210B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF370
|
|
| * | F42520210B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF370
|
|
| * | B512520210B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF370
|
|
| * | F42520210B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF370
|
|
| * | B512520220B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF400
|
|
| * | F42520220B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF400
|
|
| * | B512520220B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF400
|
|
| * | F42520220B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF400
|
|
| * | B512520230B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF430
|
|
| * | B512520230B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF430
|
|
| * | B512520240B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF450
|
|
| * | F42520240B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF450
|
|
| * | B512520240B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF450
|
|
| * | F42520240B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF450
|
|
| * | B512520250B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF470
|
|
| * | F42520250B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF470
|
|
| * | B512520250B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF470
|
|
| * | F42520250B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF470
|
|
| * | B512520260B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF500
|
|
| * | F42520260B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF500
|
|
| * | B512520260B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF500
|
|
| * | F42520260B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF500
|
|
| * | B512520270B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF550
|
|
| * | F42520270B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF550
|
|
| * | B512520270B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF550
|
|
| * | F42520270B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF550
|
|
| * | B512520280B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF600
|
|
| * | F42520280B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF600
|
|
| * | B512520280B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF600
|
|
| * | F42520280B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF600
|
|
| 11 | E8400150 | BALL-STEEL | 4 | ||
| 12 | 920620-0 | винт выпускной | 1 | ||
| 13 | 00B303-0 | Комплект винтов | 3 | ||
| 3 | 06L348-2 | Кольцо | 1 | ||
| 4 | 13L462-1 | NUT-GLAND | 1 | ||
| K | F12620100 | Ремкомплект / комплект уплотнений (ремкомплект) | 1 | ||
| K10 | E6651450 | Кольцо | 1 | ||
| K5 | E6060470 | WIPER-DUST | 1 | ||
| K6 | E5302940 | U-PACKING | 1 | ||
| K7 | E6501150 | Кольцо | 1 | ||
| K8 | 00R511-0 | RING-SLYD | 2 | ||
| K9 | E6311441 | Кольцо уплотнительное (О-кольцо) | 1 | ||
| N | @ | NOT INDIVIDUALLY SUPPLIED | AR | ||
| N* | F42520230B | FREE LIFT CYL ASSY | 1 |
HBF15T,TF430
|
|
| N* | F42520230B | FREE LIFT CYL ASSY | 1 |
HBF18T,TF430
|
|
| N1 | @ | TUBE ASSY | 1 | ||
| N2 | @ | ROD ASSY | 1 |
