Каталог запчастей
-
Hyundai
-
HDF15/18-5
- MAIN BEARING CASE
MAIN BEARING CASE погрузчика дизельного Hyundai HDF15/18-5
MAIN BEARING CASE погрузчика дизельного Hyundai HDF15/18-5 со списком деталей и комплектацией. Каждую деталь можно приобрести в наличии и под заказ с дотавкой по всей России
Код подсистемы:9090
Наименование:MAIN BEARING CASE
Версия:
MAIN BEARING CASE HDF15/18-5
| Поз. | Код | Наименование | Кол | Прим. | |
|---|---|---|---|---|---|
| 010 | 1A041-07093 | BRG CASE ASSY-WHEEL | 1 | ||
| 020 | 1A091-04540 | BOLT-CASE & BRG | 2 | ||
| 030 | 1A091-23480 | METAL-CRANKSHAFT | 1 |
STD SET
|
|
| 030 | 1A091-23930 | METAL-CRANKSHAFT | 1 |
-0.2MM SET
|
|
| 030 | 1A091-23940 | METAL-CRANKSHAFT | 1 |
-0.4MM SET
|
|
| 040 | 1A091-04362 | GASKET-BEARING CASE | 1 | ||
| 050 | 1G851-04810 | COVER-BEARING CASE | 1 | ||
| 060 | 1A091-04820 | GASKET-CASE COVER | 1 | ||
| 070 | 01123-50825 | Болт | 8 | ||
| 080 | 01123-50828 | Болт | 8 | ||
| 090 | 1G911-04460 | Сальник | 1 | ||
| 100 | 1A091-07043 | MAIN BEARING CASE ASSY | 1 | ||
| 110 | 1A091-04540 | BOLT-CASE & BRG | 2 | ||
| 120 | 1A091-23480 | METAL-CRANKSHAFT | 1 |
STD SET
|
|
| 120 | 1A091-23930 | METAL-CRANKSHAFT | 1 |
-0.20MM SET
|
|
| 120 | 1A091-23940 | METAL-CRANKSHAFT | 1 |
-0.40MM SET
|
|
| 130 | 1A091-07053 | MAIN BEARING CASE ASSY | 1 | ||
| 140 | 1A091-04540 | BOLT-CASE & BRG | 2 | ||
| 150 | 1A091-23480 | METAL-CRANKSHAFT | 1 |
STD SET
|
|
| 150 | 1A091-23930 | METAL-CRANKSHAFT | 1 |
-0.20MM SET
|
|
| 150 | 1A091-23940 | METAL-CRANKSHAFT | 1 |
-0.40MM SET
|
|
| 160 | 1A091-07063 | MAIN BEARING CASE ASSY | 1 | ||
| 170 | 1A091-04540 | BOLT-CASE & BRG | 2 | ||
| 180 | 1A091-23480 | METAL-CRANKSHAFT | 1 |
STD SET
|
|
| 180 | 1A091-23930 | METAL-CRANKSHAFT | 1 |
-0.20MM SET
|
|
| 180 | 1A091-23940 | METAL-CRANKSHAFT | 1 |
-0.40MM SET
|
|
| 190 | 15601-04560 | Болт корпуса подшипника | 3 |
