FREE LIFT CYLINDER(3 STAGE) погрузчика на сжиженном газе Hyundai HLF20/25/30CII
FREE LIFT CYLINDER(3 STAGE) погрузчика на сжиженном газе Hyundai HLF20/25/30CII со списком деталей и комплектацией. Каждую деталь можно приобрести в наличии и под заказ с дотавкой по всей России
Код подсистемы:7190
Наименование:FREE LIFT CYLINDER(3 STAGE)
Версия:
FREE LIFT CYLINDER(3 STAGE) HLF20/25/30CII
| Поз. | Код | Наименование | Кол | Прим. | |
|---|---|---|---|---|---|
| * | F42520210B | FREE LIFT CYL ASSY | 1 |
20/25C-2,TF370
|
|
| * | F42520220B | FREE LIFT CYL ASSY | 1 |
20/25C-2,TF400
|
|
| * | F42520240B | FREE LIFT CYL ASSY | 1 |
20/25C-2,TF450
|
|
| * | F42520250B | FREE LIFT CYL ASSY | 1 |
20/25C-2,TF470
|
|
| * | F42520260B | FREE LIFT CYL ASSY | 1 |
20/25C-2,TF500
|
|
| * | F42520270B | FREE LIFT CYL ASSY | 1 |
20/25C-2,TF550
|
|
| * | F42520280B | FREE LIFT CYL ASSY | 1 |
20/25C-2,TF600
|
|
| * | F42520310B | FREE LIFT CYL ASSY | 1 |
HLF30C-2,TF370
|
|
| * | F42520320B | FREE LIFT CYL ASSY | 1 |
HLF30C-2,TF400
|
|
| * | F42520330B | FREE LIFT CYL ASSY | 1 |
HLF30C-2,TF430
|
|
| * | F42520340B | FREE LIFT CYL ASSY | 1 |
HLF30C-2,TF450
|
|
| * | F42520360B | FREE LIFT CYL ASSY | 1 |
HLF30C-2,TF500
|
|
| * | F42520370B | FREE LIFT CYL ASSY | 1 |
HLF30C-2,TF550
|
|
| * | F42520380B | FREE LIFT CYL ASSY | 1 |
HLF30C-2,TF600
|
|
| 11 | E8400150 | BALL-STEEL | 4 |
HLF20/25C-2
|
|
| 12 | 920620-0 | винт выпускной | 1 |
HLF20/25C-2
|
|
| 13 | 00B303-0 | Комплект винтов | 3 |
HLF20/25C-2
|
|
| 3 | 06L348-2 | Кольцо | 1 |
HLF20/25C-2
|
|
| 33 | 13L463-2 | Кольцо | 1 |
HLF30C-2
|
|
| 34 | 13L458-2 | NUT-GLAND | 1 |
HLF30C-2
|
|
| 4 | 13L462-1 | NUT-GLAND | 1 |
HLF20/25C-2
|
|
| 41 | E8400150 | BALL-STEEL | 4 |
HLF30C-2
|
|
| 42 | 920620-0 | винт выпускной | 1 |
HLF30C-2
|
|
| 43 | 00B303-0 | Комплект винтов | 3 |
HLF30C-2
|
|
| K | F12620100 | Ремкомплект / комплект уплотнений (ремкомплект) | 1 | ||
| K | F12620200 | Ремкомплект / комплект уплотнений (35-40) | 1 |
HLF30C-2
|
|
| K10 | E6651450 | Кольцо | 1 |
HLF20/25C-2
|
|
| K35 | E6060500 | WIPER-DUST | 1 |
HLF30C-2
|
|
| K36 | E5310700 | U-PACKING | 1 |
HLF30C-2
|
|
| K37 | E6501240 | Кольцо | 1 |
HLF30C-2
|
|
| K38 | 00R514-0 | RING-SLYD | 2 |
HLF30C-2
|
|
| K39 | E6311501 | Кольцо уплотнительное (О-кольцо) | 1 |
HLF30C-2
|
|
| K40 | E6651490 | Кольцо | 1 |
HLF30C-2
|
|
| K5 | E6060470 | WIPER-DUST | 1 |
HLF20/25C-2
|
|
| K6 | E5302940 | U-PACKING | 1 |
HLF20/25C-2
|
|
| K7 | E6501150 | Кольцо | 1 |
HLF20/25C-2
|
|
| K8 | 00R511-0 | RING-SLYD | 2 |
HLF20/25C-2
|
|
| K9 | E6311441 | Кольцо уплотнительное (О-кольцо) | 1 |
HLF20/25C-2
|
|
| N | @ | NOT INDIVIDUALLY SUPPLIED | AR | ||
| N* | F42520230B | FREE LIFT CYL ASSY | 1 |
20/25C-2,TF430
|
|
| N* | F42520350B | FREE LIFT CYL ASSY | 1 |
HLF30C-2,TF470
|
|
| N1 | @ | TUBE ASSY | 1 |
HLF20/25C-2
|
|
| N2 | @ | ROD ASSY | 1 |
HLF20/25C-2
|
|
| N31 | @ | TUBE ASSY | 1 |
HLF30C-2
|
|
| N32 | @ | ROD ASSY | 1 |
HLF30C-2
|
