Каталог запчастей
-
Hyundai
-
HSL600T/680T
- INSULATION
INSULATION минипогрузчика серии T Hyundai HSL600T/680T
INSULATION минипогрузчика серии T Hyundai HSL600T/680T со списком деталей и комплектацией. Каждую деталь можно приобрести в наличии и под заказ с дотавкой по всей России
Код подсистемы:1016
Наименование:INSULATION
Версия:
INSULATION HSL600T/680T
| Поз. | Код | Наименование | Кол | Прим. | |
|---|---|---|---|---|---|
| 1 | YCAC-01541 | INSU-BULKHEAD PLATE | 1 | ||
| 10 | YCAC-01529 | INSU-RR CORNER POST LH | 1 | ||
| 11 | YCAC-01531 | INSU-LOW WINDOW C/TRIM | 1 | ||
| 12 | YCAC-01525 | INSU-BATT BOX COVER | 1 | ||
| 13 | YCAC-01524 | INSU-BACK PANEL UPPER | 1 | ||
| 14 | YCAC-01547 | INSU-ENG CVR SHEET | 1 | ||
| 15 | YCAC-01548 | INSU-TANK TIE | 1 | ||
| 16 | YCAC-01537 | INSU-ROPS OUTER BLANKET | 1 | ||
| 17 | YCAC-01546 | INSU-PUMP MTG PLATE | 1 | ||
| 18 | YCAC-01538 | INSU-RR F/PLATE RR SIDE | 1 | ||
| 19 | YCAC-01523 | INSU-BACK PANEL LOWER | 1 | ||
| 2 | YCAC-01540 | INSU-SEAT PLATE | 1 | ||
| 20 | YCAC-01539 | INSU-INSPECT COVER | 2 | ||
| 21 | YCAC-01530 | INSU-SIDE PANEL LH | 1 | ||
| 22 | YCAC-01542 | INSU-SIDE SHIELD LH | 1 | ||
| 23 | YCAC-01544 | INSU-LOWER TRANS LH | 1 | ||
| 24 | YCAC-01528 | INSU-CAB MTG FILLER LH | 1 | ||
| 3 | YCAC-01526 | INSU-FR STEP SHIELD | 1 | ||
| 4 | YCAC-01532 | INSU-CAB MTG FILLA RH | 1 | ||
| 5 | YCAC-01543 | INSU-SIDE SHIELD RH | 1 | ||
| 6 | YCAC-01545 | INSU-LOWER TRANS RH | 1 | ||
| 7 | YCAC-01534 | INSU-SIDE PANEL RH | 1 | ||
| 8 | YCAC-01527 | INSU-HEADLINER FOSS | 1 | ||
| 9 | YCAC-01533 | INSU-RR CORNER POST RH | 1 |
