Каталог запчастей
-
Volvo Construction Equipment
-
L90 L90
- Comfort drive control lever steering
Comfort drive control lever steering погрузчика колесного Volvo Construction Equipment L90 L90
Comfort drive control lever steering погрузчика колесного Volvo Construction Equipment L90 L90 со списком деталей и комплектацией. Каждую деталь можно приобрести в наличии и под заказ с дотавкой по всей России
Код подсистемы:2119
Наименование:Comfort drive control lever steering
Версия:91221, 91469
Comfort drive control lever steering L90 L90
| Поз. | Код | Наименование | Кол | Прим. | |
|---|---|---|---|---|---|
| VOE 11992384 | Ptd Circuit Bd | 1 | |||
| VOE 11992385 | Ptd Circuit Bd | 1 | |||
| VOE 11023416 | Relay box | 1 |
SER NO 8290 -
|
||
| VOE 11993230 | Rubber bellows | 1 | |||
| VOE 11993513 | Knob | 1 | |||
| VOE 955779 | Hexagon nut | 1 |
SER NO 9678 -
|
||
| VOE 955779 | Hexagon nut | 1 |
SER NO 9678 -
|
||
| VOE 955143 | Cross recessed screw | 1 |
SER NO 9678 -
|
||
| VOE 955143 | Cross recessed screw | 1 |
SER NO 9678 -
|
||
| VOE 955144 | Cross recessed screw | 1 |
SER NO 9678 -
|
||
| VOE 956063 | Cross recessed screw | 1 |
SER NO 9678 -
|
||
| VOE 956063 | Cross recessed screw | 1 |
SER NO 9678 -
|
||
| 1 | VOE 4803464 | Переключатель | 1 | ||
| 10 | VOE 955780 | Hexagon nut | 1 | ||
| 10 | VOE 955780 | Hexagon nut | 1 | ||
| 11 | VOE 4786690 | Реле | 1 |
RE24, RE25
|
|
| 11 | VOE 4786690 | Реле | 1 |
RE24, RE25
|
|
| 12 | VOE 11018329 | Control Unit | 1 | ||
| 13 | VOE 956074 | Cross recessed screw | 1 | ||
| 13 | VOE 956074 | Cross recessed screw | 1 | ||
| 14 | VOE 11018328 | Cable harness | 1 | ||
| 15 | VOE 11041628 | Cable harness | 1 | ||
| 16 | VOE 11039120 | 11039120 | 1 | ||
| 17 | VOE 11041627 | Cable harness | 1 | ||
| 18 | VOE 4803549 | 4803549 | 1 | ||
| 19 | VOE 11992216 | Knob | 1 | ||
| 2 | VOE 4803491 | Lens | 1 | ||
| 20 | VOE 11048027 | Control lever | 1 | ||
| 21 | VOE 955140 | Cross recessed screw | 1 |
SER NO - 9677
|
|
| 21 | VOE 955140 | Cross recessed screw | 1 |
SER NO - 9677
|
|
| 22 | VOE 955891 | Шайба | 1 |
SER NO - 9677
|
|
| 22 | VOE 955891 | Шайба | 1 |
SER NO - 9677
|
|
| 23 | VOE 355780 | Knob | 1 |
SER NO - 9677
|
|
| 24 | VOE 1503867 | Lens | 1 |
SER NO - 9677
|
|
| 25 | VOE 13949607 | Шайба | 1 | ||
| 25 | VOE 13949607 | Шайба | 1 | ||
| 26 | VOE 952629 | Зажим | 1 | ||
| 26 | VOE 952629 | Зажим | 1 | ||
| 27 | VOE 956092 | Cross recessed screw | 1 | ||
| 27 | VOE 956092 | Cross recessed screw | 1 | ||
| 28 | VOE 11041653 | Cable harness | 1 | ||
| 29 | VOE 6646637 | Contact housing | 1 | ||
| 29 | VOE 6646637 | Contact housing | 1 | ||
| 3 | VOE 11041563 | Cable harness | 1 | ||
| 30 | VOE 4803274 | Диод | 1 | ||
| 30 | VOE 4803274 | Диод | 1 | ||
| 32 | VOE 955143 | Cross recessed screw | 1 |
SER NO - 9677
|
|
| 32 | VOE 955143 | Cross recessed screw | 1 |
SER NO - 9677
|
|
| 33 | VOE 4881440 | Cable tie | 1 | ||
| 33 | VOE 4881440 | Cable tie | 1 | ||
| 4 | VOE 11041564 | Cable harness | 1 | ||
| 6 | VOE 955143 | Cross recessed screw | 1 | ||
| 6 | VOE 955143 | Cross recessed screw | 1 | ||
| 7 | VOE 11018261 | Decal | 1 | ||
| 8 | VOE 11023432 | Cable harness | 1 | ||
| 9 | VOE 956075 | Cross recessed screw | 1 | ||
| 9 | VOE 956075 | Cross recessed screw | 1 |
